Stober - C102G0093EZ503U
| Manufacturer | Stober |
|---|---|
| Part Number | C102G0093EZ503U |
| Inner Code | 4735958 |
| Description | Synchronous Servo Motor with Gearboxes |
| Custom Code | 85015220 |
| Technical specification | MV0000009180 Standstill current 7.67 A Nominal current 6.90 A Translation 9.326 Math. exact translation 3180/341 Motor torque 9.70 Nm Standstill torque 100 Nm Output torque 88 Nm Max. input speed 6,000 rpm cycle Motor speed 3,000 1/min Output speed 322 1/min Motor power 3.05 kW Spinning game 15 arcmin Load characteristic 1.2 Solid shaft design with key Shaft size Ø25x50 with pass. *200549 Case design threaded hole Installation position EL5 Double output shaft seal Mobilgear 600 XP 220 Lubrication * CLP ISO VG 220 Type designation EZ Motor EZ503UDFPQ6O119 Cooling type convection cooling IC Drive controller manufacturer STOBER compatible External drive controller assignment con.23 DC link voltage 540V ZKS/400VAC * Drive controller type/MDS/SDS 5 connector/ compatible Connection diagram 442321 EnDat Multiturn digital encoder Encoder type Ind. EnDat 2.2 EQI 1131 * Rated speed nN 3000 rpm 540V (KEM=119) Plug type angle rotatable Matching plug Without mating plug Power connection 8-pin connector con.23 Position of connectors 90° PTC thermal coil protection in the power connection Thermal class (VDE 0530) 155 F Protection class (EN 60529) IP56 (EN 60529) Design STOBER logo/motor paint UR/CSA Recognized Components version option Mass inertia dynamic design S1 Operating mode Servo Motors K painting/1-layer painting Color RAL 9005 deep black Painting options output not painted Documentation language German Documentation language English |
Please contact us to request a price quote for Stober - C102G0093EZ503U, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
