Steimel - PSF2-20RD-131027R
| Manufacturer | Steimel |
|---|---|
| Part Number | PSF2-20RD-131027R |
| Inner Code | 4587907 |
| Description | pump |
| Custom Code | 84136039 |
| Technical specification | P-SF2/20RD-VL, gear pump, 2-20 bar FKM, suitable for motor IEC 90, B3/B5, with mounting screws Gear pump: SF 2/20RD - VL Item no.: PSF2-20RD-131027R Dimension sheet: DPA052D-090LMF-R33 Spare parts list: DET052020RD-150R Suction and pressure connection: G 1/SAE Material design: Housing parts: GG-25 Pinion shafts: case hardened steel 16MnCrS5 helically toothed, flanked Storage: multi-layer MD Shaft seal: radial shaft seal elastomers: FKM Pumping medium: lubricating oil Viscosity: 50-5000 cSt Delivery data: approx. 27 l/min pressure: 10 bar Rotational speed: 1450 rpm pressure relief valve Setting range: 2 - 20 bar Opening pressure: 12 bar Rotation direction: right with coupling: BKUA040-1424-301 with bellhousing: BLA052200110LA21 suitable for three-phase motor Design/size: B3/B5/IEC 90 Paint: primed (HDO058, green) Type plate: ETY924-D-E—PE01 |
Please contact us to request a price quote for Steimel - PSF2-20RD-131027R, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
