Steimel - ASF2-13RD-162652R
| Manufacturer | Steimel |
|---|---|
| Part Number | ASF2-13RD-162652R |
| Inner Code | 431260 |
| Description | Pump lubrication |
| Custom Code | 84136039 |
| Technical specification | A-SF2/13RD-VLFM, pump unit, 2-20 bar 1.1kW, 1500, 230/400V, 50Hz, IP55, F, B5, IE3 Gear pump unit: SF 2/13 RD - VLFM Product no.: ASF2-13RD-162652R Dimension sheet: DPA052D-090LFM-R33 Spare part list: DET052013RD--165R Suction and pressure connection: G 1/SAE 1 Housing parts: EN-GJL-250 (GG-25) Sprocket shafts, noise-opti.: 16MnCrS5, egh., oblique Storage: multi-layer MD Shaft sealing: radial shaft seal Elastomers: FKM Pumping medium: lubricating oil Viscosity: 50-5000 cSt Temperature: 10-60°C Flow rate: approx. 18.5/22 l/min. Pressure: 5 bar Speed: 1450/1740 rpm pressure relief valve Opening pressure: 8 bar Adjustment range: 2-20 bar Direction of rotation: right Test run: yes, with HLPD 46 Coupling: BKUA040-1424-301 Pump carrier with foot: BLF052200110LA21 Three-phase motor: LDM090-04-903 Motor data: Output 1/2:1.1/1.2 kW Speed 1/2:1500/1800 rpm Voltage/frequency 1:230/400 volts at 50 Hz Voltage/frequency 2:265/460 volts at 60 Hz Efficiency class: IE3 Protection class: IP 55 Insulation class: F Design: B 5 Aggregate paint: without Type plate: ETY924 |
| Weight | 25 |
Please contact us to request a price quote for Steimel - ASF2-13RD-162652R, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
