Stahl - ST 1005-8/2 1/1
| Manufacturer | Stahl |
|---|---|
| Part Number | ST 1005-8/2 1/1 |
| Inner Code | 4823771 |
| Custom Code | 84251100 |
| Technical specification | Item no. A1432010010 HD class according to DIN EN 13001-2 HD1 M4 engine classification M4 load carrier classification IP protection class IP55 Place of use in the hall Ambient temp. min -20 °C Ambient temp. max +40 °C CE certification HOIST Load capacity 500 kg Lifting height (max) 5,000 m Lifting speed slow. 2.00 m/min Quick lift speed 8.00 m/min Number of pins 8/2 Lifting motor type E21 Fine stroke output 0.20 kW Main stroke power 0.80 kW ED fine lift 20% ED main stroke 40% Fine stroke 240 circuits Main stroke 120 circuits Chain type load chain galvanized Item ID Rope 1/Chain 331 006 9 Length of chain 1 5,470 m Plastic chain storage RSN 012 load handling device type CHASSIS Stationary version Chassis type - - - Hanger Hook hanger Drive motor rated frequency 0 Hz ELECTRICS Contactor control Crane builder protection control no Lifting motor rated frequency 50 Hz Operating voltage 400 V Control voltage 48 V Frequency 50 Hz Operating limit switch without STH control unit Control cable nominal length 3.800 PAINTING Polyurethane coating Cat layer thickness 80 μm Body colour RAL 7021, black grey Colour of branding parts RAL 6018, yellow green |
Please contact us to request a price quote for Stahl - ST 1005-8/2 1/1, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
