Stahl - P/N: 168660, Type: 9460/12-08-11
| Manufacturer | Stahl |
|---|---|
| Part Number | P/N: 168660, Type: 9460/12-08-11 |
| Inner Code | 1799265 |
| Description | Analog input module |
| Custom Code | 85363010 |
| Technical specification | Analog input module Explosion-protected Version : Ex i inputs, 8 channels For 2-conductor transmitter Application range (zones) : 1 , 2 , 21 , 22 Ex interface zone : 0 , 1 , 2 , 20 , 21 , 22 Installation in Div. NEC 500 : (Class I) 1/2 & (Class II, III) 1/2 Ex interface in Div. NEC 500 : (Class I) 1/2 & (Class II, III) 1/2 Max. voltage Uo : 26,2 V Max. current Io : 86 mA Max. power Po : 561 mW Min. ambient temperature : -20 °C Max. ambient temperature : +65 °C Gas explosion protection : II 2 (1) G Ex ib [ia Ga] IIC T4 Gb Dust explosion protection : II (1) D [Ex ia Da] IIIC |
Please contact us to request a price quote for Stahl - P/N: 168660, Type: 9460/12-08-11, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
