Stahl - ET-208-TX-W00-DC-GL / 243335
| Manufacturer | Stahl |
|---|---|
| Part Number | ET-208-TX-W00-DC-GL / 243335 |
| Inner Code | 3852041 |
| Description | Raptor device platform |
| Custom Code | 84714108 |
| Technical specification | ET-208-TX-40103000003-000500000000 field system consisting of: 236504 Operator Interface 200 SERIES Raptor device platform Tipo: ET-208-TX-W00-DC-GL Technology: RAPTOR Operator Interface Range of use (zones): 1, 2, 21, 22 Display version: Sunlight readable Backlight: LED technology Display size inches: 7 Display size cm: 18 Display resolution: WVGA 800 x 480 pixels Display format: 15:9 Display brightness: 500 cd/m2 Touch screen: capacitive Touch screen material: glass Front panel: glass on aluminum Front design: front installation Processor type: Cortex A8, 800 MHz RAM: 512 MB Data storage: 1 GB Media interface: 10/100BaseTX (Ex e) Maximum cable length: max. 100 m Connector type: terminals Serial interface: 1xRS422/485, 1xRS422 (Ex e) USB interface: 1 x USB Ex ib, 1 x USB Ex e Integrated audio amplifier: No Heating available: Yes Operating system: to be specified Operating voltage: 24 VDC Ambient temperature °C: -40... 70 °C Ambient temp. Continuous operation: +65 °C 290mm x 146mm x 83mm Case protection type (IP) front: IP66/IP69 housing protection. (IP) Back: IP54 Certifications & Approvals: ATEX China (CNEX) Korea (KCC) Korea (KGS) China (CCC) IECEx India (BIS) United Kingdom (UKCA) Russia (EAC) NEC CEC India (PESO) Model BIS: ET-208-TX-W00-DC-GL Gas explosion protection: II 2 G Ex eb ib q [ib] IIC T4 Gb Dust explosion protection: II 2 D Ex tb ib [ib] IIIA T115°C Db For more information, see: r-stahl.com Webcode ET208A 236528 SPlusRT 200 SPSPlusWIN Runtime for 200 series Note: requires SPSPlusWIN version 6x or newer 236527 WEC7 Windows® Embedded Compact 7 Languages: en image on the device/drive Certificate of Authenticity on the back of the case Licence information in the operating instructions FSB RU0000046423 SPSPlusWIN 6 license |
Please contact us to request a price quote for Stahl - ET-208-TX-W00-DC-GL / 243335, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
