| Manufacturer | Stahl |
|---|---|
| Part Number | 9170-20/20-14-11 |
| Inner Code | 4254457 |
Please contact us to request a price quote for Stahl - 9170-20/20-14-11, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
(Control Unit System Series ConSig 8040 explosion proof)
Control device system Series ConSig 8040 explosion-protected
Control device system
Control Unit System Series 8040 Start-Stop-Potentiometer
THE UPPER PART OF THE ENGINE CONTROL BOX EXProof in the middle RED LIGHT GREEN SIGNAL START (1) THE BOTTOM RED BUTTON STOP (0) BUTTON
Control device system Series ConSig 8040 explosion-protected
Control Unit System Series 8040 LED lamp green and control switch 8008,4 pole
Travel drive for SY 13211313 GW, 2 pieces of 332,825 s / n Fab.-Nr. 7510074
(Micro Limit Switch type 8064 ATEX Certificate: PTB 02 ATEX 1031 X Connecting cable, H05VV-F, 0.75 mm2 Cable length 3m Plastic roller)
position switch
Positionsschalter explosionsgeschützt
Junction box Ex
Junction Boxes Series 8102
Juction box Ex e explosion -protected
(Junction box Ex e explosion-proof Rated operating voltage AC 750 V, conductor: 10 mm2, Housing material: polyester resin glass fiber reinforced, dimensions (W x H x D): Application mm 145 x 145 x 71 (zones): 1, 2, 21, 22, protection (IP): IP66, gas explosion: II 2 G Ex e IIC T6, dust explosion: II 2 D Ex tD A21 80 ° C, ambient temperature, min .: -40 ° C, ambient temperature max .: +55 ° C, 8 ST mantle terminals 10 mm2, 6 ST cable entry black M25 Ø 7 ... 17 mm, 4 ST sealing plug M25 x 1.5)
Junction Boxes
Terminal box Ex e
Art. Nr.134710, terminal boxes Rated voltage: 1000 V
Art.Nr.134718, terminal boxes Rated voltage: 1000 V
STATION: CONTROL START/STOP WITH START PUSH BUTTON (GREEN COLOR) WITH EMERGENCY STOP PUSH BUTTON (RED COLOR) WITH TWO INDICATING LAMPS EXPLOSION-PROOF: II 2G EEx ed IIC T6,IP66 ENCLOSURE MATERIAL: STAINLESS STEEL DIMENSIONS: 176MM X 176MM X 91MM
Terminal box
Increased Safety Exe Dual Certified ATEX / IECEx. SIZE: 360mm x 360mm x 91mm. MAX QTY OF ENTRIES PER FACE: 1xM20x1.5 & 1xM32x1.5. Tapped Entries. Terminal Type: WDU2.5, Terminal Quantity: 82, and Terminal Type: WDU4, Terminal Quantity: 12. Required Quantity: 12pcs. Arrangement: 08816E00 Stopper Plug
Box EEx e, T5, C side M20x1.5 6 pcs. / D M25h1,5 1pc. M20x1.5 2 pcs.
8146/2073 terminal box Ex i MaterialNr.: 8146259110
Control stationType : 8146/5061Technical data:Gas - Explosion protection: Ex II 2 G Ex de IIC T6 GbDust - Explosion protection: Ex II 2 D Ex tb IIIC T80°C Db IP66Certificate ATEX: PTB 01 ATEX 1024Certificate IECEx: IECEx PTB 06.0090Material: Polyester resinDimension: 170 x 227 x 91 mmDegree of protection: IP 66Ambient temperature: -20° C ... +40° CRated voltage: 230 V / 50 HzRated current: 6 AControl voltage: V / HzWiring diagram: Without wiringAlso certified to: on request1 pc(s) rotary actuator bk 64mm not lockableLabel 8602 ø51, engravablelabelling: OFF-Auto-Handcontrol switch 4-pole switch. options 1171 pc(s) bezel 72x72 for measuring instrumentdirekt meas. ammeter 72 x 72 mm 4-20/40mA0-20A1 pc(s) earth terminal USLKG 5
-special switch Ex II 2G Ex de IIC T6 containing : -1 8544/1-31 switch 3 pole 690V, 63A -1 black turn knob, 0/OFF – I/ON -1 external earth 10qmm -1 internal earth rail -2 M32 cable connectors type 32A2F
Distribution fuse
disconnect
