Stahl - P/N: 150854, Type: 8571/11-506
| Manufacturer | Stahl |
|---|---|
| Part Number | P/N: 150854, Type: 8571/11-506 |
| Inner Code | 173198 |
| Description | switch socket |
| Custom Code | 85366990 |
| Technical specification | Switch socket explosion-proof Type: 8571/11-506 Rated operating voltage AC: 200 - 240 V 346 - 415 V Frequency range: 50 - 60 Hz Rated operating voltage DC: 0 V 0 V Detailed number of poles: 5 P (3 P + N + PE) Code colour: red Coding (clock setting): 6 Case material: polyamide Application area (zones): 1, 2, 21, 22 Scope: European Union (ATEX) IECEx Min. ambient temperature: -30 °C Max. ambient temperature: +55 °C Rated operating current: 32 A Gas explosion protection: II 2 G Ex db eb IIC T5 Gb Dust explosion protection: II 2 D Ex tb IIIC T75 °C Db Ambient temperature max.2: +40 °C Gas explosion protection2: II 2 G Ex db eb IIC T6 Gb Dust explosion protection2: II 2 D Ex tb IIIC T60 °C Db Protection class (IP): IP66 Introductions: 2 x M32 x 1.5 Cable and line entries: 1 x M32 x 1.5 Introduction 1 type: 8161/7-M32-2109 Cable entry material: black polyamide Line diameter: 9... 21 mm Sealing plug: 1 x M32 x 1.5 Sealing plug material: black polyamide Plate with threaded holes: with 2 x M32 x 1.5 |
| Weight | 2.2 |
Please contact us to request a price quote for Stahl - P/N: 150854, Type: 8571/11-506, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
