Stahl - 8146/5-V37-306-51-1090-K

Manufacturer Stahl
Part Number 8146/5-V37-306-51-1090-K
Inner Code 3310311
Description Sicherheitsschalter
Technical specification 205629 Sicherheitsschalter gemäß Auftrag Typ : 8V37/… Technische Daten: Typenbezeichnung: 8146/5-V37-306-51-1090-K Ausführung gemäß: Explosionsschutz (Gas): Ex II 2 G Ex db eb IIC T6 Gb Explosionsschutz (Staub): Ex II 2 D Ex tb IIIC T80 °C Db ATEX Zertifikat: PTB 01 ATEX 1024 IECEX Zertifikat: IECEx PTB 06.0090 Weitere Zertifikate: auf Anfrage Schutzart (IP): IP66 Umgebungstemperatur: -40 °C .... +42 °C/-40 °C .... +40 °C; max. -40 °C .... +57 °C Gehäuse Material: Polyesterharz glasfaserverstärkt Bemessungsspannung [Un]: 690 V/ 500 V Bemessungsstrom [In]: 63/80A Bemessungsfrequenz [Fn]: 50/60 Hz Anschlussquerschnitt: >= 16/ 25 mm² Material Typschilder: Klebeschild Bemerkungen: Schaltleistung nach IEC/EN 60947-3; DIN VDE 0660, Teil 107 Trennereigenschaften nach IEC/EN 60947-3; DIN VDE 0660 1 ST Sicherheitsschalter, 63/80A, 3-polig Hilfskontakte: linker Schacht: 1 Schließer (EIN nacheilend) + 1 Öffner rechter Schacht: Kein Hiko gewählt Gehäusedeckel: In Schalterstellung EIN Abnehmbar, in AUS-Stellung verriegelt 1 ST Schaltgriff: 3fach abschließbar in AUS-Stellung mit Vorhängeschlössern Griff rot, Schutzkragen gelb Leitungseinführungen: unten mit Messingplatte: 2 ST CMP-32E1FW KLE MsNi M32 Klemmbereich: 23,7 - 33,9mm 1 ST CMP-20s/16E1FW KLE MsNi M20 Klemmbereich: 6,1 - 13,1mm HS Warennummer: 85365080 DE
Weight 7.55

Please contact us to request a price quote for Stahl - 8146/5-V37-306-51-1090-K , or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.


WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.

Stahl-8146/5-V37-306-51-1090-K price
