Stahl - 8040/1280Z-40XXXXN99

Manufacturer Stahl
Part Number 8040/1280Z-40XXXXN99
Inner Code 3368707
Custom Code 85369095
Technical specification 130929 Befehlsgerätesystem Reihe ConSig 8040 gemäß Auftrag Typ : 8040/ Technische Daten: Typenbezeichnung: 8040/12 Ausführung gemäß: Explosionsschutz (Gas): Ex II 2 G Ex eb IIC T6 Gb Explosionsschutz (Staub): Ex II 2 D Ex tb IIIC T80°C Db ATEX Zertifikat: PTB 01 ATEX 1105 IECEX Zertifikat: IECEx PTB 06.0025 Weitere Zertifikate: auf Anfrage Schutzart (IP): IP66 Umgebungstemperatur: -40 °C .... +40 °C Gehäuse Material: Polyesterharz Material Typschilder: Klebeschild Bemerkungen: Einbaulage: Seite D unten 1 ST Vorsatz 64x64 fuer Messgeraet Skalenschild 8405/6 gem. Spez. Skala: 0-40/80A Strommesser 1A Ue=2 fach Wandler 1 ST Seite: unten 8161/7-M25-1707-LT KLE sw HS Warennummer: 85369095 DE
Weight 0.49

Please contact us to request a price quote for Stahl - 8040/1280Z-40XXXXN99 , or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.


WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.

Stahl-8040/1280Z-40XXXXN99 price

More products of Stahl

  • 136678 8146/5041

    control box Type: 8146/5041 Technical specifications: Gas - Explosion protection: Ex II 2 G Ex de IIC T6 Gb Dust - Explosion protection: Ex II 2 D Ex tb IIIC T80 ° C Db IP66 Test Certificate ATEX: PTB 01 ATEX 1024 Test certificate IECEX: IECEx PTB 06.0090 Material: Polyester resin Dimensions: 112 x 170 x 91 mm IP 66 Ambient temperature: -20 ° C ... + 40 ° C Rated voltage: 230 V / 50 Hz Rated current: 6 A Control voltage: V / Hz Schematic: Without wiring Other Approval: on request 1 ST Pilzschluesseltaster EMERGENCY STOP MS 1 Contact element Oe + S 1 ST protective conductor terminal USLKG 5 1 ST: Lower 8161/5 M20-13-fitting M20x1,5sw

  • 137051 / 8146/1051 TERMINAL BOX EX E

    Technical data: Gas - Explosion protection: Ex II 2 G Ex e II T6 Dust - Explosion protection: Ex II 2 D Ex tD A21 IP66 T 80 °C Certificate ATEX: PTB 01 ATEX 1016 Certificate IECEx: IECEx PTB 06.0046 Material: Polyester resin Dimension: 170 x 170 x 91 mm Degree of protection: IP 66 Ambient temperature: - 40°C ... + 40°C Rated voltage: 550 V Cross section: 2.5 mm² Also certified to: on request Fitting position: side D bottom, rail horizontal 12 pc(s) line-up terminal WDU 2,5/E labelling: 1-12 1 pc(s) TS35 mounting rail TS35 in enclosure 8146 for terminals length: 133mm 1 pc(s) 8146 PE-Rail 7x4 mm² gn-ye 1 pc(s) Side: bottom 8161/5-M25-17 cable gland M25x1,5 black 1 pc(s) Side: left 8161/5-M25-17 cable gland M25x1,5 black 3 pc(s) Side: left 8161/5-M16-10 cable gland M16x1,5 black 1 pc(s) Side: right 8161/5-M25-17 cable gland M25x1,5 black 3 pc(s) Side: right 8161/5-M16-10 cable gland M16x1,5 black CCT No.: 85369085 DE Net weigth: 0,770 KG

  • 137051 . 8146/1051 TERMINAL BOX EX E

    Technical data: Gas - Explosion protection: Ex II 2 G Ex e II_ Dust - Explosion protection: Ex II 2 D Ex tD A21 IP66 Certificate ATEX: PTB 01 ATEX 1015U Certificate IECEx: IECEx PTB 06.0044U Material: Polyester resin Dimension: 170 x 170 x 91 mm Degree of protection: IP 66 Ambient temperature: - 20 °C ... + 55 °C Rated voltage: - V Cross section: - mm² Also certified to: on request Fitting position: side D bottom, rail horizontal 1 pc(s) TS15 mounting rail TS15 in enclosure 8146 for terminals length: 133mm 1 pc(s) Side: bottom 8161/5-M25-17 cable gland M25x1,5 black 1 pc(s) Side: left 8161/5-M25-17 cable gland M25x1,5 black 2 pc(s) Side: left 8161/5-M16-10 cable gland M16x1,5 black 1 pc(s) Side: right 8161/5-M25-17 cable gland M25x1,5 black 2 pc(s) Side: right 8161/5-M16-10 cable gland M16x1,5 black CCT No.: 85369085 DE Net weigth: 0,770 KG

  • 138382

    Blanking Plug

  • 138382 BLANKING PLUGS F. CABLE GLANDS M25.....25PCS

    .CCT No.: 39269097 DE Net weigth: 0,130 KG

  • 138383

    (nut M16 brass nickel plated 50pcs Locknut, metric brass, nickel plated Internal thread d: M16 x 1.5 Width across flats [mm]: 19 Packing unit: 50pieces CCT No.: 74153300 IN Net weigth: 0,135 KG)

  • 138383 NUT M16 BRASS NICKEL PLATED 50PCS

    .Locknut, metric brass, nickel plated Internal thread d: M16 x 1.5 Width across flats [mm]: 19 Packing unit: 50pieces CCT No.: 74153300 IN Net weigth: 0,135 KG

  • 138389

    nut M20x1.5

  • 138394

    Blanking Plug

  • 138395

    (nut M25 brass nickel plated 50pcs Locknut, metric brass, nickel plated Internal thread d: M25 x 1.5 Width across flats [mm]: 29 Packing unit: 50pieces CCT No.: 74153300 IN Net weigth: 0,348 KG)

  • 138395 NUT M25 BRASS NICKEL PLATED 50PCS

    .Locknut, metric brass, nickel plated Internal thread d: M25 x 1.5 Width across flats [mm]: 29 Packing unit: 50pieces CCT No.: 74153300 IN Net weigth: 0,348 KG

  • 138406

    (blanking plugs f. cable glands Pg9 /M16.....50pcs CCT No.: 39269097 DE Net weigth: 0,061 KG)

  • 138406 BLANKING PLUGS F. CABLE GLANDS PG9 /M16.....50PCS

    .CCT No.: 74153300 IN Net weigth: 0,061 KG

  • 138417

    (blanking plugs f. multiple cable glands, d 5,5mm...50pcs CCT No.: 39269097 DE Net weigth: 0,031 KG)

  • 239156

    Cable gland with reduction sealing insert explosion-protected

  • 138474 8161/5-M25-96

    .Cable gland Ex e polyamide, 4x4-6mm, 50 pcs Cable Glands Series 8161, explosion protected Version: 8161/5 Ex e (black) Thread size: M25 x 1.5 Number of entries: 4 Cable dia. range [mm]: 4 ... 6 For use in: Zones 1 & 2, 21 & 22 CCT No.: 39269097 DE Net weigth: 1,000 KG

  • 138482

    8161/5-M16-9 Cable gland Ex e polyamide, 4-9mm, 50 pcs Cable Glands Series 8161, explosion protected Version: 8161/5 Ex e (black) Thread size: M16 x 1.5 Number of entries: 1 Cable dia. range [mm]: 4 ... 9 For use in: Zones 1 & 2, 21 & 22

  • 138520 8161/5-M25-17

    (Cable Glandsexplosion-protectedType : 8161/5-M25-17Thread size : M25Thread length : 10 mmMaterial : PolyamideColour : blackClamping range : 7 ... 17 mm2Cable armour : Unarmoured cablesApplication range (Zone) : 1 , 2 , 21 , 22Type of protection (IP) : IP66Gas explosion protection : II 2 G Ex e IIDust explosion protection : II 2 D Ex tD A21Min. ambient temperature : -40 °CMax. ambient temperature : +75 °CCCT No.: 39269097 DENet weigth: 0,020 KG)

  • 138772 8163/2-20-A2F-M20 CABLE GLAND

    .Cable Glands Ex d and Ex e for Unarmoured Cables Series 8163/2-A2F, explosion protected Thread size C: M20 x 1.5 Cable diameter A: min.6.5 max.14.0 PVC-shroud: HV 05 Version: BS 6121, EN 50262 For use in: Zones 1 & 2, 21 & 22 CCT No.: 85369010 GB Net weigth: 0,070 KG

  • 143524 8290/3-M25 STOPPING PLUG M25X1,5

    .Stopping Plugs Series 8290, explosion protected Thread size: M25 x 1.5 Material: Polyamide Colour: black For use in: Zones 1 & 2, 21 & 22 CCT No.: 39269097 DE Net weigth: 0,007 KG

  • 143544 8290/3-M25

    (Stopping Plug explosion-protected Type : 8290/3-M25 Material : Polyamide Thread size : M25 Drive : Hexagon socket Application range (Zone) : 1 , 2 , 21 , 22 Gas explosion protection : II 2 G Ex e IIC Gb Dust explosion protection : II 2 D Ex tb IIIC Db Min. ambient temperature : -60 °C Max. ambient temperature : +80 °C Packaging unit : 100 CCT No.: 85389099 DE Net weigth: 0,700 KG)

  • 143554 8290/3-M16 STOPPING PLUG M16X1,5

    .Stopping Plugs Series 8290, explosion protected Thread size: M16 x 1.5 Material: Polyamide Colour: black For use in: Zones 1 & 2, 21 & 22 CCT No.: 85389099 DE Net weigth: 0,003 KG

  • 143556 8290/3-M16

    (Stopping Plug explosion-protected Type : 8290/3-M16 Material : Polyamide Thread size : M16 Drive : Hexagon socket Application range (Zone) : 1 , 2 , 21 , 22 Gas explosion protection : II 2 G Ex e IIC Gb Dust explosion protection : II 2 D Ex tb IIIC Db Min. ambient temperature : -60 °C Max. ambient temperature : +80 °C Packaging unit : 100 CCT No.: 85389099 DE Net weigth: 0,300 KG)

  • 143707 REDUCTION EXPLOSION-PROTECTED TYPE : 8295/1R1-M25X1,5 M20X1,5

    .External thread : M25 x 1.5 Internal thread : M20 x 1.5 Wrench size : A/F32 Material : Steel galvanized Version : Metric / Metric Application range (Zone) : 1 , 2 Gas explosion protection : II 2 G Ex e II Min. ambient temperature : -55 °C Max. ambient temperature : +130 °C Certificate IECEX Gas : IECEx PTB 06.0075U Certificate ATEX Gas : PTB 02 ATEX 1067 U For further information, see : www.r-stahl.com Web code 8295A Adaptors Metric / Metric, galvanized steel, explosion protected External thread d1: M25 x 1.5 Internal thread d2: M20 x 1.5 Width across flats [mm]: 32 CCT No.: 73181900 DE Net weigth: 0,073 KG

  • 145280

    8491 / 11-230 horn with horn 230V, AC

  • 145285

    8491 / 21-230 Flachhupe 230V, AC

  • 150579

    8570/12-306 Plug 2P+PE 16A 200-250V, 60+60Hz, 6h, blue

  • 155399

    (Push button explosion-protected Type : 8602A0001-1 Enclosure material : Polyamide Seal : Standard Mounting : with threaded Application range (Zone) : 1 , 2 , 21 , 22 Gas explosion protection : II 2 G Ex e II Dust explosion protection : II 2 D Ex tD A21 Min. ambient temperature : -20 °C Max. ambient temperature : +70 °C Type of protection (IP) : IP66 Packed : Yes)

  • 155476

    (Rotary handle, large, raised explosion-protected Type : 8602A0724-1-ss-0 Enclosure material : Polyamide Seal : Silicone Mounting : with threaded Padlockable in : no position Application range (Zone) : 1 , 2 , 21 , 22 Gas explosion protection : II 2 G Ex e II Dust explosion protection : II 2 D Ex tD A21 Min. ambient temperature : -50 °C Max. ambient temperature : +70 °C Type of protection (IP) : IP66 Packed : Yes)

  • 155785

    (Label I O II)
