Stahl - 209263 / 6149/2-5211-5010
| Manufacturer | Stahl |
|---|---|
| Part Number | 209263 / 6149/2-5211-5010 |
| Inner Code | 146433 |
| Description | LED inspection light explosion-proof |
| Custom Code | 94054039 |
| Technical specification | Design: standard version Color rendering: >= 80 Color temperature: 5,000 K height: 52 mm Construction width: 52 mm Length: 595 mm Case material: aluminum Lamp power: 16 W Diffuser: with diffuser Luminous flux: 1,000 lm Luminaire efficiency: 63 lm/W Tube material: polycarbonate Protection class: II (protective insulation) Number of lamps: 1 diameter: 52 Fittings: 1 CMP-20s-A2F cable entry. Holes: - Connection cable fine-wired max.: 1.50 mm2 Light source: LED double row Rated current: 0.130 A Rated operating voltage AC: 110.00 - 240.00 V Frequency range: 50 - 60 Hz Rated operating voltage DC: 110.00 - 240.00 V Application area (zones): 1, 2, 21, 22 Gas explosion protection: II 2 G Ex d IIC T4 Gb Dust explosion protection: II 2 D Ex tb IIIC T100 °C Db Ambient temperature min.: -30 °C Ambient temperature max.: +60 °C Cable length: 5 m Type of connection cable: H07RN-F 2x1.5 qmm Protection class (IP): IP66/IP67 Protection class IP (IEC 60598): - |
| Weight | 1.4 |
Please contact us to request a price quote for Stahl - 209263 / 6149/2-5211-5010, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
