Stahl - P/N: 273999, Type: 6149/2-3511-5011
| Manufacturer | Stahl |
|---|---|
| Part Number | P/N: 273999, Type: 6149/2-3511-5011 |
| Inner Code | 3900370 |
| Description | LED inspection light explosion-proof |
| Custom Code | 94054039 |
| Technical specification | Execution: Standard execution Color rendering:> = 80 Color temperature: 5,000 K. Light color: neutral white Height: 52 mm Width: 52 mm Length: 595 mm Housing material: aluminum Silicone-free: silicone-free Lamp power: 13 W. Diffuser: with diffuser Luminous flux: 1,396 lm Luminaire efficiency: 104 lm / W Tube material: polycarbonate Protection class: II (protective insulation) Number of lamps: 1 Diameter: 52 Illuminant: LED single row Nominal current: 0.700 A. Rated operational voltage AC: 24.00 - 48.00 V Frequency range: 50 - 60 Hz Rated operational voltage DC: 24.00 - 48.00 V Area of application (zones): 1, 2, 21, 22 Gas explosion protection: II 2 G Ex d IIC T4 Gb Dust explosion protection: II 2 D Ex tb IIIC T100 ° C Db Ambient temperature min. : -40 ° C Ambient temperature max. : +60 ° C Cable length: 5 m Type of connection cable: H07RN-F 2x1.5 qmm Degree of protection (IP): IP66 / IP67 Degree of protection IP (IEC 60598): - |
Please contact us to request a price quote for Stahl - P/N: 273999, Type: 6149/2-3511-5011, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
