Stahl CraneSystems - SH 3008-20 4/1 L2 / A0343030040
| Manufacturer | Stahl CraneSystems |
|---|---|
| Part Number | SH 3008-20 4/1 L2 / A0343030040 |
| Inner Code | 4918422 |
| Description | Electric cable |
| Custom Code | 84251100 |
| Technical specification | created taking into account the necessary content from the Product Safety Act (Machinery Directive 2006/42/EC, Low Voltage Directive 2014/35/EU), product-related EN standards and BGV. HD class according to DIN EN 13001-2 HD3 M5 engine classification M5 load rating IP protection class IP55 Place of use in the hall Ambient temperature min -20 °C Ambient temperature max +40 °C CE certification HOIST Load capacity 3,200 kg Lifting height (input) 6,000 m Lifting height (max) 6,000 m Slow lifting speed 1.00 m/min Fast lifting speed 6.00 m/min Number of hoists 1 Number of poles 12/2 Hoist motor type H33 Fine stroke power 0.50 kW Main lift output 3.50 kW ED fine stroke 20% ED main lift 50% Feinhub 360 circuits Main stroke 180 circuits Rope diameter 7.0 mm Item ID rope 1/chain 330 005 9 Cable length 27.800 m Hook bottle type H125-4 CHASSIS Electric vehicle version. Short installation height Type KE-S 33 chassis Slow travel speed 6.30 m/min Fast driving speed 25.00 m/min Number of tractors cat 1 Traction drive type complete SF17113123 Fine driving power 0.11 kW Main drive power 0.44 kW ED fine driving 20% ED main driving 40% Cat flange width 306 mm ELECTRICS Contactor control Crane builder protection control yes Hoist motor nominal frequency 60 Hz Traction motor control frequency 60 Hz Operating voltage 575 V Control voltage 120 V Frequency 60 Hz Stroke Switch Type 125.04 SMC22 overload protection Load measurement sensor LCP/LCD pressure sensor PAINTING Polyurethane coating or SP powder Cat layer thickness 80 µm Body colour RAL 7021, black grey Color of branding parts RAL 6018, yellow green |
Please contact us to request a price quote for Stahl CraneSystems - SH 3008-20 4/1 L2 / A0343030040, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
