Stahl CraneSystems - SH 5025-10 4/1 L3 ex
| Manufacturer | Stahl CraneSystems |
|---|---|
| Part Number | SH 5025-10 4/1 L3 ex |
| Inner Code | 4714927 |
| Technical specification | Produced taking into account the necessary content from the Product Safety Act (Machinery Directive 2006/42/EC, Low Voltage Directive 2014/35/EU), product-related EN standards and BGV HD class according to DIN EN 13001-2 HD1 M5 engine classification Carrying device classification M5 IP protection class IP55 Place of use in the hall Ambient temperature min 0 °C Ambient temp. max + 55 ATEX certification Ex-zone ZONE 1 Ex device category Ex II 2 G... Gb Explosion protection Ex db eb IIB T4 LIFTING EQUIPMENT load 10,000 kg Lifting height (input) 10,000 m Lifting height (max.) 10,000 m Slow lift speed 0.40 m/min Fast lift 2.50 m/min Number of hoists 1 Number of poles 2/12 A4 lift motor Fine stroke power 0.71 kW Main stroke power 4.80 kW ED Fine lift 15% ED Main lift 30% Feinlift 180 circuits Main Hub 180 circuits Rope diameter 12.5 mm Item ID Rope 1/Chain 330 009 9 Cable length 45,300 m Hook bottle type H226-4 CHASSIS Stationary version Chassis type - - - Slow speed 0.00 m/min Fast travel speed 0.00 m/min Number of cat 0 drives ELECTRICS Contactor control Crane grocer control yes Pluggable controller no Lifting motor rated frequency 50 Hz Drive motor control frequency 50 Hz Operating voltage 400 V 230 V control voltage Frequency 50 Hz Stroke Switch Type 125.02 SLE22 overload protection Load measurement sensor LCP/LCD pressure sensor PAINTING Polyurethane coating or SP powder layer thickness Cat 80 μm Body colour RAL 7021, black grey Branding parts color RAL 6018, yellow green |
Please contact us to request a price quote for Stahl CraneSystems - SH 5025-10 4/1 L3 ex, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
