SITI - MP71MU50-212-T3A71.2-4
| Manufacturer | SITI |
|---|---|
| Part Number | MP71MU50-212-T3A71.2-4 |
| Inner Code | 4859021 |
| Description | worm gear motor |
| Custom Code | 8483 4025 |
| Technical specification | SITI - worm gear motor worm gear motor MP71-MU 50-212-T3A 71.2 T3A 71.2 T3A 71.2-4 Power (kW) 0.37 Output speed (rpm) 1400/6.6 Translation 212 (3.03 x 70) Output torque (Nm) max. 85 (with S1 operation) Output torque (Nm) 240 Operating factor fB 0.35! Voltage 230/400V Switching mode star/triangle Frequency (Hz) 50 Rated current (A) at 400V 1.02A Motor protection class IP55 Insulation class F Efficiency class IE3 Efficiency at 100% load 77.3% Hollow shaft diameter (mm) 25 H7 with spring groove in accordance with DIN 6885/1 Installation position B3 Terminal box position/ cable entry 1 (top)/4 (left) Lubricant synth. oil Viscosity 320 Lubricant amount (l) 0.1/0.19 l Alu housing varnishing - Gearbox unpainted - RAL 9006 engine Weight 16 kg operating manual CE mark yes |
Please contact us to request a price quote for SITI - MP71MU50-212-T3A71.2-4, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
