Sensus - S620D01E
| Manufacturer | Sensus |
|---|---|
| Part Number | S620D01E |
| Inner Code | 3331324 |
| Description | ring piston water meter |
| Technical specification | 620 G1 1/4" (R1") 260mm Q3_10 R80 any installation, cold water up to 40°C Compliance Charges Catalog number S620D015 Nominal diameter DN25 Product Specification Inline Installation arbitrary Connection (input and output) G 1 1/4" x G 1 1/4" (R 1") installation length: 260 mm Housing material brass according to DIN 50930 Part 6 Metrology MID Nominal flow Q3_10 Class/Ratio (Messverh.) R 80 Temperature range T 50 Counter plastic, dry runner Label/seal conformity mark. /P.Wire Barcode Type 2/5 interleaved (default) Barcode attachment barcode lasered Inscription Standard Germany Packaging individual carton Sparked pointer Unspecified Dry Runner with Roller Counter for cold water up to DN20: all installation positions (except “overhead”) from DN25: all mounting positions (except “overhead”), not suitable for downpipe Standard HRI AMR interface for remote reading, M-Bus or wireless solutions Special design features: * Optional: with built-in plug-in backflow preventer |
| Weight | 4 |
Please contact us to request a price quote for Sensus - S620D01E, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
