Sensus - MSTML612
| Manufacturer | Sensus |
|---|---|
| Part Number | MSTML612 |
| Inner Code | 4775859 |
| Description | Woltmann water meter |
| Custom Code | 90282000 |
| Technical specification | MeiStream DN125 Compliance fee Catalog number: MSTML612 Nominal size (DN) DN 125 Product type meter Pressure stage PN16 Installation length 250 mm Drilling pattern EN 1092 PN16 Cobalt blue (cold) /tin coating RAL5013 Metrology 2014/32/EU (MID) Module H1 Nominal flow rate Q3 = 160 m³/h Class/ Ratio (measurement ratio) HIGHWAY 63 Horizontal/vertical installation position (H/V) T 50 temperature identification TVO KTW+W270 (standard) Mechanical counter Unit m³ Case/ME addition flow straightener (SGR) HRI-MEI module (Wired GWZ MEI B (M-Bus/MiniBus) 30° variants Pulse type 4: Balanced Imp. /Tamp. (-) Output pulse value 100 l/IMP. Pulse length 500 ms Cable length/connection 3 m Scanned pointer 10 litres/revolution (DN40-125) 8-digit liter protocol Data transmission type M-Bus/MiniBus Woltmann dry runner with an encapsulated counter. Rotatable counter. Measuring blade parallel to the pipe axis. * universal installation position (version “plus” only horizontal) * standard HRI AMR interface for remote reading or M-Bus * optional: e-register with integrated radio readout . Special design features: * “floating impeller” for maximum measurement accuracy * Measuring inserts (cold water) compatible with WP-Dynamic design * available in all common lengths (WP and WS) * very high load capacity * minimized wear * unique measurement range * Flood-proof in accordance with protection class IP 68 Technical data in accordance with list sheet LB 1010, LB 1020, LB 1060, LB 1080 |
Please contact us to request a price quote for Sensus - MSTML612, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
