Schmalz - VM-BASIC-125-90-4-1600 EVE4
| Manufacturer | Schmalz |
|---|---|
| Part Number | VM-BASIC-125-90-4-1600 EVE4 |
| Inner Code | 1954562 |
| Description | vacuum lifter |
| Custom Code | 84289090 |
| Technical specification | 12.02.12.00016 Type: VM-BASIC-125-90-4-1600 EVE4 VacuMaster Basic vacuum lifter for hanging into a crane hook. Type: VM-BASIC-125-90-4-1600 Suitable for continuously swiveling workpieces around 90° with a weight of up to 125 kg at 60% vacuum Weight: approx. 79 kg Construction height: approx. 800 mm Composed of: 1 piece: VacuMaster MOD-VM-BAS-125/250-90-4 400/460 basic module for: VacuMaster Basic Model size: 125/250 Design: swivel 90° with: EVE-TR dry rotor pump Suction rate: 4 m³/h Voltage: 400/460V - AC3 Frequency: 50/60 Hz Pump power: 0.18 kW Drive power: 0.72 kW color: Base body: RAL 7035, light grey Cover: RAL 5002, ultramarine blue Construction: - dry rotor rotary vane pump 50Hz: 3~300-450V 60Hz: 3~350-520V - electric linear drive for continuous swiveling of the workpieces Turn-on time: 12% - Swivel the control element with 2 buttons horizontal/vertical (mounted on the control bar) - Motor protection switch - Vacuum filter with easy-to-change filter cartridge - vacuum check valve - electronic warning device (acoustic), works even in the event of a power failure - Vacuum pressure gauge with red/green display - Spiral cable for connection to the chain hoist with extension length 3000 mm 1 piece: VacuMaster control bar for ergonomic operation BB-VM-BASIC-400-H/90 for: VacuMaster Basic Control bar length: 400 mm Construction: - error-proof manual slide valve - Bracket for attaching a chain control element 1 piece: Traverse (lengthwise) TRAV-Lang-90x90x1600-6 cross section: 90 x 90 mm Length L: 1600 mm Storage volume: 6.4 l for: VacuMaster number of outputs: 6 Construction: - integrated vacuum storage and distributor - Grooves for attaching crossbars or direct suction device connection - Material: anodized aluminum 2 pieces: Traverse (transverse) Trav-Cross-40x40x750-90x90 cross section: 40 x 40 mm Length: 750 mm Traverse connection: 90x90 Material: galvanized steel - High-strength crossbar connection Plastic allows lightweight Scratch-free movement of Crossbar 4 pieces: Suction holder for connection to a traverse HTR-S-VM-40x40-GEL-G1/2-AG Traverse connection: 40x40 Design: articulated Vacuum connection: G1/2"-AG - High-strength crossbar connection Plastic allows lightweight Scratch-free movement of Suction plates 4 pieces: Suction plate (round), universal for smooth and slightly rough surfaces SPU 210 NBR-55 G1/2-IG B Installation size: 210 Suction cup material: nitrile rubber NBR Material hardness: 55°Sh Vacuum connection: G1/2"-IG Additional equipment: sheet metal sealing edge An initial safety test in accordance with CE and DGUV rule 100-500 (formerly: BGR 500) has been implemented. The general warranty is 24 months, without wear parts. Used equipment is subject to legal regulations Warranty in accordance with Schmalz's terms and conditions. The vacuum lifter comes with a detailed and easy-to-understand technical documentation delivered (1 copy in paper form). This is in the standard languages German, English, French, Italian, Spanish and Dutch available. |
| Weight | 79.114 |
Please contact us to request a price quote for Schmalz - VM-BASIC-125-90-4-1600 EVE4, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
