Satron - VDU4/5SG402SN0N1
| Manufacturer | Satron |
|---|---|
| Part Number | VDU4/5SG402SN0N1 |
| Inner Code | 4623800 |
| Description | Differential Pressure Transmitter |
| Technical specification | Span min: 4kpa (40mbar) Span max: 250 kPa (2500 mabar) Measuring range: -100...+250 kPa (-1000...2500 mbar) Output: 4-20mA DC/HART® Process Connections: G1-thread, metal / metal taper sealing Extension length: 0 mm Wetted materials Diaphragm: AISI316L Filling oil: Silicone oil Housing type, master: Housing with junction box/terminal strip, display, inlet M20x1,5 Exposion proof: No explosion proof classification Process temperature: -30...+125°C Cable between sensors PUR cable with M12 connector both end of cable Preset: 0-1480 mmH2O |
Please contact us to request a price quote for Satron - VDU4/5SG402SN0N1, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
