Santerno - ZZ0176021
| Manufacturer | Santerno |
|---|---|
| Part Number | ZZ0176021 |
| Inner Code | 4521076 |
| Description | Inverter |
| Technical specification | SINUS H 0002 4T BA2K2 Size S1 kW 0.75 SINUS - H SENSORLESS VECTOR CONTROL INVERTER - V/F. IGBT inverter, IP20 degree of protection as standard IP66 NEMA4X up to 22 Kw, Three-phase 400 Vac power supply, 2 control technologies: V/F constant/quadratic pair and Sensorless Vector Control with high torque development, RS 485 serial port with protocol MODBUS RTU (115 kbps), Smart remote keyboard (7 segments — 8 keys), operation for normal applications (120% Inom overload) or for heavy applications (150% Inom overload. ), Maximum output frequency 400Hz, anti-stall and anti-trip algorithm, 8 speed sets, 3 jumps of frequency, 7 programmable digital inputs, 2 analog inputs 0-10Vdc and 4-20mA, 1 input a pulse train, 1 multifunction open collector output, 1 multifunction relay output, 1 output analog 0-10VDC/4-20mA, 1 pulse train output, (0.5 - 32 Khz), adjustable carrier 1-10kHz, Integrated brake module, automatic and manual torque boost, Speed search, Function PID, S-Ramps, Fire Mode function, EMC compliant with EN 61800-3, industrial network, SECOND ENVIRONMENT, estimation of the life cycle of the capacitor bank, integrated STO function. Options: Profibus DP, ProfiNet, CANOpen, Modbus TCP, Ethernet/IP. |
Please contact us to request a price quote for Santerno - ZZ0176021, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
