Santerno - ZZ0102031 74003 / SINUS PENTA 0086 4T BA2K2
| Manufacturer | Santerno |
|---|---|
| Part Number | ZZ0102031 74003 / SINUS PENTA 0086 4T BA2K2 |
| Inner Code | 4908717 |
| Description | INVERTER |
| Technical specification | 75 kw Size S20 HP 100 A133/A145/A155 Sinus PENTA: universal INVERTER with 5 functions to choose from (V/F — VTC — FOC — SYN — RGN) Single product, 5 functions: - vector modulation IFD function for most applications (V/f curve) - simple sensorless vector VTC function for applications with high torque performance (Vector Torque Control - direct torque control) - closed loop vector FOC function for applications with high torque development (up to +30%) and wide speed range (Field Oriented Control - Vector field orientation) - vector SYN function for applications with IE4+ permanent magnet synchronous motors - RGN function with low harmonic content to the network (THDi ≤ 5%) and COsΦ=1 (optional) The automation applications integrated into the SINUS PENTA line represent a simple solution and economic in the management of SERVODIAMETERS, MULTIPUMP systems, HVAC systems, motors Master-Slave and MULTIPOSITIONERS. Software compiled on PC for programming more than 20 application functions (card required) optional) — Wide power supply range: from 200 Vac three-phase to 690 Vac three-phase. Integrated EMC filters with low ground dispersion over the entire range in accordance with EN55011 gr. 2 CL.a on emission limits - Does not require a line contactor with STO (Safe Torque Off) system in accordance with EN 61800-5-2 (SIL3) and EN ISO 13849 (PL d) (See Safe Torque Off Function - Application Manual) . - Compact size - Intelligent cooling system - Integrated braking module up to SINUS 162 - More quiet motor with carrier frequency up to 16kHz and “Silent Motor” function - Control direct PTC motor thermal probe for ATEX zone - Simple start-up with preset parameters for the most common applications - Extended 12-key control panel and large display - Adjustment of output frequency from 0 to 1000Hz (2000Hz with application) - Controlled motor stop up to speed zero in the event of a power supply failure - Master-slave function for the operation of multiple motors connected on the same mechanical shaft - Automatic calibration for the recognition of motor characteristics - Maximum torque 200% - PID function - Frequency jumps - Integrated digital potentiometer - Tester integrated multifunction - Integrated motor thermal protection - Automatic direct current braking - Programmable acceleration and deceleration multiramps - Feedback from a tachometric dynamo or encoder - 8 programmable digital inputs - 3 analog inputs 0-10Vdc, 0 (4) -20Ma (2 differentials, 1 in sum) - 2 outputs configurable as relays with exchange contacts - 2 open collector outputs - Auxiliary voltages 24Vdc, 10Vdc - 3 outputs configurable analog 0-10Vdc, 0 (4) -20mA - RS485 serial communication with MODBUS RTU protocol — Rampe ad S. - STANDARD TROPICALIZATION FOR AGGRESSIVE ENVIRONMENTS with a strong presence of H2S (Centrals Geothermal energy, wastewater treatment plants, etc...) - HIGH ELECTRICAL EFFICIENCY (deriving from applications photovoltaic) Performance at full load ≥ 97.5%. High current and time overload — Reduced harmonic emission to the network and low output radio frequency emission (does not require RF filtering for environments in cl. A2) — DNV marine certification for installation in naval environments. |
Please contact us to request a price quote for Santerno - ZZ0102031 74003 / SINUS PENTA 0086 4T BA2K2, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
