Saia-Burgess - 9300087.J5Z1-M
| Manufacturer | Saia-Burgess |
|---|---|
| Part Number | 9300087.J5Z1-M |
| Inner Code | 5048839 |
| Description | Microswitch |
| Custom Code | 85365080 |
| Technical specification | XCG3-J5-Z1 XC micro switch - Model size: subminiature - Operating force: 0.6 N (contact opening: 0.4 mm) - Connections: solder, 4.0 x 3.6 x 0.5 mm (opening: 2.4 x 1.3 mm) - Circuit diagram: changeover (CO) - Actuator: J5 lever, straight, l=40 mm - Contact material: solid silver rivet - Housing material: Duroplast melamine formaldehyde (olive + black) - Approval: ENEC, UL, CSA - Protection class: IP40 - Special feature: - |
Please contact us to request a price quote for Saia-Burgess - 9300087.J5Z1-M, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
