Saia-Burgess - V4NCSK20A1G-1080 MM
| Manufacturer | Saia-Burgess |
|---|---|
| Part Number | V4NCSK20A1G-1080 MM |
| Inner Code | 4479893 |
| Description | V4NC microswitch |
| Technical specification | 9101060-A1-M - Actuation force: 0.9 N - Connections: assembled with FLRY-A cables, 3x0.5 mm², brown (COM), orange-black (NO), white-purple (NC), l=1,080 mm, 2-component PU potting, K2 potting box (h=8.7 mm max.) - Connection position: opposite plunger - Switching scheme: changeover contact (CO) - Actuator: A1 lever, straight, l=18.0 mm - Actuator position: plunger side - Contact material: galvanically gold-plated solid Silver-nickel rivet - Housing material: PA6.6 GF 33% (black) - Approval: - - Degree of protection: IP6K7 - Special feature: - |
Please contact us to request a price quote for Saia-Burgess - V4NCSK20A1G-1080 MM, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
