Saia-Burgess - IFRM 18P17A4/L / 11111676
| Manufacturer | Saia-Burgess |
|---|---|
| Part Number | IFRM 18P17A4/L / 11111676 |
| Inner Code | 4429469 |
| Description | Proximity switches |
| Technical specification | Ind. proximity switch General data Installation type: quasi flush Nominal switching distance Sn: 8 mm Switching hysteresis: 3... 20% of Sr Switching status indicator: red LED Electrical data Switching frequency: < 500 Hz +Vs operating voltage range: 6... 36 VDC Max. current consumption (no load): 10 mA Output circuit: PNP normally open contact (NO) Voltage drop Vd: <2 VDC output current: < 200 mA short-circuit proof: yes Reverse polarity resistant: yes Mechanical data Design: cylindrical threaded Material (active face): PBT Housing material: nickel-plated brass Size: 18 mm Case length: 65 mm Connection type: cable, 2 m Max. tightening torque: 40 Nm ambient Working temperature ፦25... +75 °C Protection type: IP 67 |
Please contact us to request a price quote for Saia-Burgess - IFRM 18P17A4/L / 11111676, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
