RTK Regeltechnik - ST 6160.A6-6G / PV 6311, 17082089/020
| Manufacturer | RTK Regeltechnik |
|---|---|
| Part Number | ST 6160.A6-6G / PV 6311, 17082089/020 |
| Inner Code | 4278080 |
| Description | pneumatic actuator |
| Custom Code | 84818059 |
| Technical specification | Supply air pressure max. 6 barue Membrane area 530 cm² Spring range 0.8.. 2.8 bar/max. stroke 40 mm Safety position: spring closes (Distribution valve: port A, mixing valve: port B) additional equipment: - Electropneum. Positioner, type SR 6136 (SIPART PS2) 2-wire connection Input 4.. 20 mA at 0% input, valve closed - Position feedback module, 2-wire connection output 4.. 20 mA (galvanically isolated) - filter pressure reducer with 10 bar pressure gauge, 1/4 NPT connection, Ex ll 2Gc LLc, -20 to +70 °C (mounted on positioner |
Please contact us to request a price quote for RTK Regeltechnik - ST 6160.A6-6G / PV 6311, 17082089/020, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
