RTK Regeltechnik - REact 30E-074 with actuator and valve.
| Manufacturer | RTK Regeltechnik |
|---|---|
| Part Number | REact 30E-074 with actuator and valve. |
| Inner Code | 4011481 |
| Technical specification | Control valve Motorized control valve - MV 5274 series in three-way form for mixing, with short B-flange Nominal size DN 25, nominal pressure PN 16 Housing material nodular cast EN-GJS-400-18-LT Flanges with sealing surface according to DIN Spindle seal: Bellows with safety stuffing box PTFE Characteristic curve / flow: linear / - Mixing cone, metallic sealing Kvs value = 9.2 m³ / h, stroke 15 mm Seat diameter 32 mm Surface treatment with zinc dust primer Max. permissible pressure according to DIN EN 1092 Max. permissible temperature TS 350 ° C Electric actuator - type REact 30E-074 Positioning force 3 kN, including manual adjustment AC motor 230 V, 50/60 Hz Adjustment speed 0.74 mm / s, stroke 15 mm Protection class IP 65 Additional equipment: - additional limit switches (2 pieces) |
Please contact us to request a price quote for RTK Regeltechnik - REact 30E-074 with actuator and valve., or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
