RTK Regeltechnik - MV 5271 (REact 30E-028)
| Manufacturer | RTK Regeltechnik |
|---|---|
| Part Number | MV 5271 (REact 30E-028) |
| Inner Code | 4767889 |
| Description | motor control valve |
| Technical specification | in three-way shape for mixing, with short B-flange Nominal diameter DN 80, nominal pressure PN 16 Housing material Ductile iron EN-GJS-400-18-LT flanges with sealing surface in accordance with DIN Spindle sealing: PTFE/carbon roof sleeves Characteristic/Anstrom.: linear/- mixing cone, metallic sealing Kvs value = 95 m³/h, stroke 25 mm seat diameter 80 mm Surface treatment with zinc dust primer CE mark in accordance with Pressure Equipment Directive (PED) max. allowable pressure in accordance with DIN EN 1092 max. allowable temperature TS 250 °C Electric actuator - type ReAct 30E-028 actuating force 3 kN, including manual adjustment AC motor 230 V, 50/60 Hz Adjustment speed 0.28 mm/s, stroke 25 mm Protection class IP 65 with pillars additional equipment: - additional limit switches (2 pieces) - Potentiometer 1000 ohms Drive rotated by 90° to flow Only for horizontal piping handwheel on the entrance side |
Please contact us to request a price quote for RTK Regeltechnik - MV 5271 (REact 30E-028), or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
