RTK Regeltechnik - PV6211K
| Manufacturer | RTK Regeltechnik |
|---|---|
| Part Number | PV6211K |
| Inner Code | 4709559 |
| Description | pneumatic control valve |
| Technical specification | Replacement for W.No. 12112117/010 in straight form Nominal diameter DN 25, nominal pressure PN 25 Housing material Ductile iron EN-GJS-400-18-LT flanges with groove in accordance with DIN 2512 Spindle sealing: Non-ferrous chloroprene roof collars Curve/Anström.: equal percent/below the cone parabolic cone, soft-sealing Kvs value = 2.5 m³/h, stroke 25 mm seat diameter 12 mm Spindle heating: heating cartridge 1 x 10 W, 24 V UC GEHOPON-EX RAL 7001 special paint (silver grey) with certificate in accordance with EN 10204-2.2 max. allowable pressure in accordance with DIN EN 1092 max. allowable temperature TS 100 °C Valve in accordance with DIN EN 12 284 Tightness test in accordance with DIN EN 12 266-1 Pneumatic actuator - type ST 6135.B6-6G Inlet air pressure max. 6 bar Membrane area 280 cm² Spring range 0.8.. 3.0 bar/max. stroke 35 mm Safety position: spring closes (Distribution valve: Gate A, mixing valve: Gate B) additional equipment: - Electric tire. Position controller, type SR 6136 (SIPART PS2) 2/3/4 wire connection Input 4.. 20 mA at 0% input, valve closed - 3/2-way solenoid valve, G 1/4 connection to 24 V DC |
Please contact us to request a price quote for RTK Regeltechnik - PV6211K, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
