RTK Regeltechnik - 21122068-0020
| Manufacturer | RTK Regeltechnik |
|---|---|
| Part Number | 21122068-0020 |
| Inner Code | 4968169 |
| Custom Code | 84818059 |
| Technical specification | Motor control valve - MV 5274 series in three-way form for mixing, with short B-flange nominal size DN 100, nominal pressure PN 16 Housing material ductile iron EN-GJS-400-18-LT Flanges with DIN sealing surface Spindle sealing: Bellows with PTFE safety plug Characteristic/flow rate: linear/- mixing cone, metallic sealing Kvs value = 148 m³/h, stroke 30 mm Seat diameter 100 mm Surface treatment with zinc dust primer CE marking in accordance with Pressure Equipment Directive (PED) max. allowable pressure according to DIN EN 1092 max. allowable temperature TS 350 °C Electrical actuator - type ReAct 30E-028 Positioning force 3 kN, including manual adjustment 230 V 50/60 Hz AC motor setting speed 0.28 mm/s, stroke 30 mm Protection class IP 65 - additional limit switches (2 pieces) |
Please contact us to request a price quote for RTK Regeltechnik - 21122068-0020, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
