RTK Regeltechnik - MV 5274, DN 20
| Manufacturer | RTK Regeltechnik |
|---|---|
| Part Number | MV 5274, DN 20 |
| Inner Code | 4745009 |
| Description | modulating valves |
| Custom Code | 84818059 |
| Technical specification | Engine Control Valve - MV 5274 Series in three-way shape for mixing, with short B-flange Nominal diameter DN 20, nominal pressure PN 16 Housing material Ductile iron EN-GJS-400-18-LT flanges with sealing surface in accordance with DIN Spindle sealing: Bellows with PTFE safety stuffing box Characteristic/Anstrom.: linear/- mixing cone, metallic sealing Kvs value = 6 m³/h, stroke 15 mm seat diameter 32 mm Surface treatment with zinc dust primer max. allowable pressure in accordance with DIN EN 1092 max. allowable temperature TS 350 °C Electric actuator - type ReAct 30E-074 actuating force 3 kN, including manual adjustment AC motor 230 V, 50/60 Hz Adjustment speed 0.74 mm/s, stroke 15 mm Protection class IP 65 - additional limit switches (2 pieces) |
Please contact us to request a price quote for RTK Regeltechnik - MV 5274, DN 20, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
