RTK Regeltechnik - MV 5391-P

Manufacturer RTK Regeltechnik
Part Number MV 5391-P
Inner Code 1802350
Description Engine control valve
Technical specification Replacement for model no. 16102131/010 in straight version, with pump freewheel Nominal size DN 50, nominal pressure PN 40 Body material cast steel EN-GP-240-GH flanges with sealing surface in accordance with DIN Spindle sealing: PTFE/carbon roof sleeves Curve/flow rate: equal percent/on the cone perforated cone with 10% freewheel, hardened (metallic sealing) Kvs value = 19 m³/h, stroke 30 mm Seat diameter 40 mm Surface treatment with zinc dust primer CE mark in accordance with the Pressure Equipment Directive (PED) max. allowable pressure according to DIN EN 1092 max. allowable temperature TS 200 °C Electric actuator - type ReAct 60E-045 Actuating force 6 kN, including manual adjustment AC motor 230 V, 50/60 Hz Operating speed 0.45 mm/s, stroke 30 mm Protection class IP 65 Additional equipment: - additional limit switches (2 pieces) - Potentiometer 1000 ohms
Weight 36

Please contact us to request a price quote for RTK Regeltechnik - MV 5391-P, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.


WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.

RTK Regeltechnik-MV 5391-P price
