RTK Regeltechnik - MV 5331
| Manufacturer | RTK Regeltechnik |
|---|---|
| Part Number | MV 5331 |
| Inner Code | 4756884 |
| Technical specification | Replacement for W.No. 14052037/020 Engine Control Valve - MV 5331 Series in three-way shape for distribution Nominal diameter DN 150, nominal pressure PN 16 Housing material Ductile iron EN-GJS-400-18-LT flanges with sealing surface in accordance with DIN Spindle sealing: PTFE/carbon roof sleeves Characteristic/Anstrom.: linear/- Distribution cone, metallic sealing Kvs value = 292 m³/h, stroke 35 mm seat diameter 125 mm Surface treatment with zinc dust primer CE mark in accordance with Pressure Equipment Directive (PED) max. allowable pressure in accordance with DIN EN 1092 max. allowable temperature TS 250 °C - without actuator - |
Please contact us to request a price quote for RTK Regeltechnik - MV 5331, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
