RTK Regeltechnik - MV 5291-V 15032511/010
Manufacturer | RTK Regeltechnik |
---|---|
Part Number | MV 5291-V 15032511/010 |
Inner Code | 5057628 |
Description | motor control valve |
Technical specification | in continuous form for boiler desalination, with sampling valve Customer connection sampling valve: Ermeto tube 12 mm nominal size DN 40, nominal pressure PN 40 Housing material: cast steel EN-GP-240-GH Flanges with DIN sealing surface Spindle sealing: PTFE/carbon roof collars Characteristic curve/flow: linear/below the cone Parabolic cone desalination valve, hardened (metallic sealing) Kvs value = 2.7 m³/h, stroke 25 mm Seat diameter 12 mm Surface treatment with zinc dust primer with certificate in accordance with EN 10204-3.1 CE marking in accordance with Pressure Equipment Directive (PED) max. allowable pressure in accordance with DIN EN 1092 max. allowable temperature TS 250 °C Electrical actuator - type ReAct 15E-038B Positioning force 1.5 kN, including manual adjustment 230 V 50/60 Hz AC motor Setting speed 0.38 mm/s, stroke 25 mm Protection class IP 65 additional equipment: - digital positioner, type repOS with display input signal: 4.. 20 mA Feedback signal: 4.. 20 mA Effective direction: at 0% valve input closed Drive spindle extended at 0% input - Potentiometer 1000 ohms |
Please contact us to request a price quote for RTK Regeltechnik - MV 5291-V 15032511/010, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
