RTK Regeltechnik - MV 5211 without actuator
| Manufacturer | RTK Regeltechnik |
|---|---|
| Part Number | MV 5211 without actuator |
| Inner Code | 5057090 |
| Description | motor control valve |
| Technical specification | - without servomotor - Motor control valve - MV 5211 series in continuous form nominal size DN 80, nominal pressure PN 16 Housing material ductile iron EN-GJS-400-18-LT Flanges according to DIN, machined according to ANSI 150 lbs. RF Spindle sealing: PTFE/carbon roof collars Characteristic/flow rate: equal percent/below the cone parabolic cone, metallic sealing Kvs value = 79 m³/h, stroke 35 mm Seat diameter 65 mm Surface treatment with zinc dust primer CE marking in accordance with Pressure Equipment Directive (PED) max. allowable pressure in accordance with DIN EN 1092 max. allowable temperature TS 250 °C |
Please contact us to request a price quote for RTK Regeltechnik - MV 5211 without actuator, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
