RTK Regeltechnik - 16022264-010
| Manufacturer | RTK Regeltechnik |
|---|---|
| Part Number | 16022264-010 |
| Inner Code | 3813945 |
| Description | Motorized control valve |
| Technical specification | Motorized control valve - series MV 5321 three-way design for mixing application nominal diameter DN 150, pressure rating PN 16 body made of spheroidal graphite iron EN-GJS-400-18-LT flanges according to DIN spindle packing: chevron rings PTFE/graphite characteristic / flow direction: linear / - mixing cone, metal sealing kvs-value = 333 m³/h, stroke 40 mm seat diameter 150 mm surface treatment with zinc dust primary coat CE-marking according PED max. allowed pressure according to DIN EN 1092 max. allowed temperature TS 250 °C Electric actuator - type REact 60E-045 actuating force 6 kN, incl. handwheel for manual operation single-phase motor 230 V, 50/60 Hz actuating speed 0.45 mm/s, stroke 40 mm protection rating IP 65 accessories: - additional limit switches (2 off) - digital valve positioner, type REpos with display input signal: 4..20 mA feedback signal: 4..20 mA effective direction: at 0 % input port B closed at 0 % input actuator spindle extended - potentiometer 1000 Ohm |
| Weight | 138 |
Please contact us to request a price quote for RTK Regeltechnik - 16022264-010, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
