RTK Regeltechnik - 15022216/010
| Manufacturer | RTK Regeltechnik |
|---|---|
| Part Number | 15022216/010 |
| Inner Code | 4855928 |
| Description | motor control valve |
| Technical specification | MV 5334 series in three-way form for distribution Nominal diameter DN 150, nominal pressure PN 16 Housing material ductile iron EN-GJS-400-18-LT Flanges with sealing surface in accordance with DIN Spindle sealing: Bellows with PTFE safety stuffing box Characteristic curve/flow: linear/- Distribution cone, metallic sealing Kvs value = 292 m³/h, stroke 35 mm seat diameter 125 mm Surface treatment with zinc dust primer CE marking in accordance with Pressure Equipment Directive (PED) Maximum allowable pressure in accordance with DIN EN 1092 max. allowable temperature TS 350 °C Electric actuator - type ReAct 60E-090 Actuating force 6 kN, including manual adjustment AC motor 230 V, 50/60 Hz Operating speed 0.90 mm/s, stroke 35 mm Protection class IP 65 Additional equipment: - additional limit switches (2 pieces) - Potentiometer 1000 ohms |
Please contact us to request a price quote for RTK Regeltechnik - 15022216/010, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
