RTK Regeltechnik - 097023-010
| Manufacturer | RTK Regeltechnik |
|---|---|
| Part Number | 097023-010 |
| Inner Code | 4071664 |
| Description | Motorized Control Valve |
| Technical specification | series MV 5274 three-way design for mixing application, shortened B-flange nominal diameter DN 80, pressure rating PN 16 body made of spheroidal graphite iron EN-GJS-400-18-LT flanges according to DIN spindle packing: bellows seal with safety stuffing box PTFE/white characteristic / flow direction: linear / - mixing cone, metal sealing kvs-value = 95 m3/h, stroke 25 mm seat diameter 80 mm surface treatment with zinc dust primary coat CE-marking according PED max. allowed pressure according to DIN EN 1092 max. allowed temperature TS 350 °C Electric actuator - type REact 30E-028 actuating force 3 kN, incl. handwheel for manual operation single-phase motor 230 V, 50/60 Hz actuating speed 0.28 mm/s, stroke 25 mm protection rating IP 65 - additional limit switches (2 off) NOTE: original unit MV5274 DN80 PN16 KV95 STK25 SEAT80 + ST5112-32 230VAC 0.26mm/s |
Please contact us to request a price quote for RTK Regeltechnik - 097023-010, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
