Robuschi - RB-C-VUOTO RVS-14/M-09
| Manufacturer | Robuschi |
|---|---|
| Part Number | RB-C-VUOTO RVS-14/M-09 |
| Inner Code | 4184303 |
| Description | pump |
| Technical specification | Motor power (kW) 4,00 Motor Poles 4 IEC motor shape B35 Water-soluble Alkyd Painting Cycle Thickness tot painting (um) 50 Final thickness vern. (um) 50 RAL Code Machine 5009 CE Certificate EC Declaration Type II A Engine type Standard motor 50hz Engine brand BRONZONI IE3 SP CE Category ATEX NON Atex RVS Vacuum Pump Series Service Type Vacuum Pump Vacuum pump size 14 Execution flanges Choice hydraulic sealing standard mechanical seal Bare axis mouth (DN) 40 Type Packaging Machine Only Protection Mouths Alim frequency. (Hz) 50 Editable Description RVS_14/M-09 Cast iron body G250. Cast-iron impeller GS400-15. Shaft common to the engine Electric form B35. G250 cast iron element. Stainless Steel Plate X5CrNiMO1712. Mechanical seal Burgmann MG12G60 BQ1VGG DIN 24960. Grease lubrication. Performance tolerance according to specification Robuschi TE3.S.0015 ** Estimated sound pressure level in free field at 1 m distance with acoustically insulated piping |
Please contact us to request a price quote for Robuschi - RB-C-VUOTO RVS-14/M-09, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
