Rexroth - R900928685 / 5-4WE 10 H3X/CG96N9K4/C
| Manufacturer | Rexroth |
|---|---|
| Part Number | R900928685 / 5-4WE 10 H3X/CG96N9K4/C |
| Inner Code | 5022126 |
| Description | Directional Control Valve |
| Technical specification | Type: Direct Operated Series: WE Fluid Type: Mineral Oil (HL, HLP) According to DIN 51524, Bio-Degradable Hydraulic Fluids HETG According to VDMA 24568 Number of Ways: 4 Number of Position: 3 Size: 10 Electrical Connection: Without Mating Connector, With Component Plug DIN EN 175301-803 Actuator Type: Solenoid/Spring Flow Rating: 120Lpm Voltage Rating: 96VDC Power Rating: 35W Seal Material: NBR Spool Action: By Springs Spool Symbol: H Viscocity: 35 - 2320 SUS Protection Class: IP 65 Pressure Rating: 210 - 315 bar Temperature Rating: -30 to 50 deg C Fluid Temperature Rating: -30 to 80 deg C Dimensions: 12.07 Inch Depth x 2.76 Inch Width x 4.61 Inch Height |
Please contact us to request a price quote for Rexroth - R900928685 / 5-4WE 10 H3X/CG96N9K4/C, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
