Rexroth - R16513142Z/ KWD-035-FNS-C1-N-1
| Manufacturer | Rexroth |
|---|---|
| Part Number | R16513142Z/ KWD-035-FNS-C1-N-1 |
| Inner Code | 4978567 |
| Technical specification | a) For O-ring Size 15: Ø 4 · 1.0 (mm) Size 20 - 45: Ø 5 · 1.0 (mm) Open lube port if necessary (see general technical notes and information in the "Maintenance" section). b) Recommended position for pin holes (dimension E4 see general technical notes and information in the "Installation" section) Rough-drilled holes may be present here from manufacturing. These may be bored open. c) Lube nipple, size 15 - 20: Funnel-type lube nipple DIN 3405-A M3x5, B2 = 1.6 mm When using different lube nipples, pay attention to the screw-in depth of 5 mm! Lube nipple, size 25 - 45: Hydraulic-type lube nipple DIN 71412-A M6x8, B2 = 9.5 mm When using different lube nipples, pay attention to the screw-in depth of 8 mm! The lube nipple is included in the scope of delivery (not installed). Connection possible on all sides. d) Sealing plugs may be present here from manufacturing. Remove before mounting. |
Please contact us to request a price quote for Rexroth - R16513142Z/ KWD-035-FNS-C1-N-1, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
