Rexnord - SR71-6 SIZE 300 (Non-standard Length)

Manufacturer Rexnord
Part Number SR71-6 SIZE 300 (Non-standard Length)
Inner Code 579649
Description THOMAS FLEXIBLE DISC COUPLING
Custom Code 84836080
Technical specification DBSE: >102mm & < 300mm (Non-standard Length) - Motor Hub Bore: 80 H6 with Keyway acc.DIN 6885 (J9) + 1 Setscrew M10 using Large Hub Design - Pump Hub Bore: 56 K7 with Keyway acc.DIN 6885 (J9) + 1 Setscrew M10 using Standard Hub Design 2 Puller Bolt Holes per Hub Stainless Steel Disc Packs Balanced per API 610, 8th Edition @ 1500rpm Max.Continuous Torque: 820Nm Service Factor based on 110kW @ 1500rpm: 1,17 Service Factor based on 75,6kW @ 1500rpm: 1,70
Weight 1

Please contact us to request a price quote for Rexnord - SR71-6 SIZE 300 (Non-standard Length), or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.


WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.

Rexnord-SR71-6 SIZE 300 (Non-standard Length) price
