Rexnord - SR71-6 SIZE 300 250mm (Standard Lengths)

Manufacturer Rexnord
Part Number SR71-6 SIZE 300 250mm (Standard Lengths)
Inner Code 578213
Description THOMAS FLEXIBLE DISC COUPLING
Custom Code 84836080
Technical specification SR71-6 SIZE 300 DBSE: 5", 5.5", 7", 140mm, 180mm or 250mm (Standard Lengths) - Motor Hub Bore: 80 H6 with Keyway acc.DIN 6885 (J9) + 1 Setscrew M10 using Large Hub Design - Pump Hub Bore: 56 K7 with Keyway acc.DIN 6885 (J9) + 1 Setscrew M10 using Standard Hub Design 2 Puller Bolt Holes per Hub Stainless Steel Disc Packs Balanced per API 610, 8th Edition @ 1500rpm Max.Continuous Torque: 820Nm Service Factor based on 110kW @ 1500rpm: 1,17 Service Factor based on 75,6kW @ 1500rpm: 1,70
Weight 1

Please contact us to request a price quote for Rexnord - SR71-6 SIZE 300 250mm (Standard Lengths), or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
