ProMinent - S3CBH040830PVTS130UA01000EN
| Manufacturer | ProMinent |
|---|---|
| Part Number | S3CBH040830PVTS130UA01000EN |
| Inner Code | 4975556 |
| Description | motor dosing pump |
| Custom Code | 84135040 |
| Technical specification | Material S3CB Sigma 3 control type B The Sigma/ 3 control type motor dosing pump is a very robust motor diaphragm dosing pump and ensures with its patented Multi-layer safety membrane for a high level of process reliability. Membrane rupture is standard with an optical Membrane rupture indicator shown, but can be used as a selected option be equipped with signaling via contact. The Sigma control type series is an intelligent pump with a 1pH wide-range power supply, 100-230 volts, 50/60Hz for safe use in many applications and offers a Wide range of drive and control variants. The removable control unit with large illuminated display offers a high level of ease of use. As control variants In addition to Pulse Control (including batch operation), can the Version via analog signal (0/4-20mA), PROFIBUS or CANopen be selected as an option in the ID code. In addition, the motor dosing pump can be equipped with relay modules (e.g. central fault message or 4-20 mA output) equipped become. The stroke length adjustment can be in the stroke adjustment range of 0-100% can be set manually in 1% steps and achieves a Reproducibility of dosing accuracy of +/- 2% in the range of 30 to 100% of the stroke length. (Observe the instructions in the documentation on this). The plastic housing protects against corrosion and enables protection class IP65. Total output range of the S3Cb series: 182-1,040 l/h, 12-4 bar (flow rate/pressure see offered pump type/identification code) Can be used for almost all liquid chemicals thanks to the available PVDF and stainless steel material variants. Our Sigma series are also available in certain versions with an FDA-compliant certificate or an EAC certificate deliverable. The “left conveyor unit” variant offers additional adjustment options for special installation situations. ID code: S3CBH040830PVTS130UA01000EN Series: S3CB - Sigma 3 control type version B Drive type: H - main drive Pump type: 04083 - 4 bar, 1040 l/h Dosing head material: PV - PVDF Seal material: T - PTFE seal Displacer material: S - multi-layer membrane opt. Anzeig Dosing head version: 1 - without vent, with valve Hydraulic connection: 3 - U-nut & E-part PVDF Version: 0 - with PM logo El. Power supply: U - 1ph, 100-240V, 50/60Hz, 420W Cable and plug: A - 2m Europe Relay function: 0 - without relay Control variant: 1 - Manual+Cont. +p.c+analog+DOS.pr Overpressure cut-off: 0 - without overpressure cut-off Control unit: 0 - HMI m.Click Wheel (0.5m cable) Access code: 0 - or access control Ü.-awake. dyn. Languages: EN - English Approval: 01 - CE Frequency: 50/60Hz Voltage: 100-240V Power: 420W Protection class: IP65 flow rate: 1040l/h Back pressure: 4bar |
Please contact us to request a price quote for ProMinent - S3CBH040830PVTS130UA01000EN, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
