Pietro Fiorentini - DIVAL 512/G 180MP
| Manufacturer | Pietro Fiorentini |
|---|---|
| Part Number | DIVAL 512/G 180MP |
| Inner Code | 2593945 |
| Description | gas pressure control device |
| Custom Code | 84811019 |
| Technical specification | Item number: FM7064206G DN 25x40 gas pressure control device, spring-loaded, fail to open, CE approved according to DGR 2014/68/EU and EN334, actuator houses EN- GJS400-15, connection G1" x G1"1/2, with integrated SBV, Ps 20 bar according to EN 12186, Pe max 20 bar, Pa max 300 mbar, Design temperature -20°C/+60°C, operating temperature EN334 - 10 (-20) °C/+60°C, with internal pulse line, optional external Pulse and blow-off or respiration connection G¼” or 10L Construction length 130 mm Pds: 0.300 bar Spring: 0.180-0.300 bar 1.1 SAV switching device LA/MP 512 (CE) DVGW FM7086505P integrated safety shut-off valve (SAV), with bypass and internal pulse hole, Wdso 140-450 guide ranges mbar, Wdsu 10-240 mbar, ventilation connection G1/8" or 10L, optional G1/4" pulse connection (closed with blind plug) Pdo: 0.440 bar spring 0.280-0.450 bar PDU: 0.180 bar spring 0.060-0.240 bar |
| Weight | 1 |
Please contact us to request a price quote for Pietro Fiorentini - DIVAL 512/G 180MP, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
