Parker - 331N03-496131C2
| Manufacturer | Parker |
|---|---|
| Part Number | 331N03-496131C2 |
| Inner Code | 4672540 |
| Description | solenoid valve |
| Technical specification | Actuation Type:Solenoid Operated Maximum Fluid Temperature:50 °C Port Size:1/4" G Power Supply Voltage:24V DC Coil Temperature Range:-40 +50 °C Insulation Class:F 155°C Flow Coefficient 1:1250 l/min Valve Type:3/2 Way Function:Spring & air return Port Type:Namur Body Material:Anodized Aluminum Media:Dry or Lubricated Air Orifice Size:7,0 mm Minimum Operating Pressure:2,5 bar Maximum Operating Pressure:10 bar Minimum Fluid Temperature:-20 °C Seal Material:NBR Coil Power Consumption:3 W Electrical Connection:2 P + E plug according to EN 175301-803 type B Coil Specifications Met:CE - EAC |
Please contact us to request a price quote for Parker - 331N03-496131C2, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
