Orbinox - EN 1092-2 PN 10 / DN 500 / Type EXN
| Manufacturer | Orbinox |
|---|---|
| Part Number | EN 1092-2 PN 10 / DN 500 / Type EXN |
| Inner Code | 4966674 |
| Technical specification | ORBINOX-KnifeGateValve Type EXN Uni-directional wafer type knife gate valve, Flanges acc. to EN 1092-2 PN 10 Diameter: DN 500 Body: GG 25, epoxy coated RAL 5015 Slide: stainless steel AISI 304 (1.4301) Piston rod: stainless steel AISI 304 (1.4301) Yoke: Steel, epoxy coated with boreholes for 18 mm proximity switches Slide cover: stainless steel AISI 304 Gland followers: up to DN 300 aluminum, from DN 350 cast iron Packing: PTFE-coated synthetic fibre (type ST) Seat: EPDM Seal retainer ring: Type A in stainless steel AISI 304 (1.4301) Actuator: Double acting tire. Actuator, aluminum Operation pressure: 5-7 bar Maximum pressure In flow direction: DN 50 to 250 = 10 bar, DN 300 to DN 400 = 6 bar DN 450 = 5 bar, DN 500 to DN 600 = 4 bar Accessories: --- without flangesealing and fixing material |
Please contact us to request a price quote for Orbinox - EN 1092-2 PN 10 / DN 500 / Type EXN, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
