Omron - VB-4121
| Manufacturer | Omron |
|---|---|
| Part Number | VB-4121 |
| Inner Code | 615197 |
| Description | Limit Switch |
| Technical specification | Circuit SPDT x 4 Switch Function On-Mom Current Rating (Amps) 10A (AC), 600mA (DC) Voltage Rating - AC 125 V Voltage Rating - DC 125 V Actuator Type Bevel Plunger Mounting Type Chassis Mount Termination Style Screw Terminal Ingress Protection IP67 - Dust Tight, Waterproof Features - Operating Force 1500gf Release Force 500gf Pretravel 0.060" (1.5mm) Differential Travel 0.020" (0.5mm) Overtravel 0.138" (3.5mm) Operating Temperature -10°C ~ 80°C Operating Position 1.024" (26.0mm) Electrical Life 300,000 Cycles Mechanical Life 5,000,000 Cycles |
| Weight | 1 |
Please contact us to request a price quote for Omron - VB-4121, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
