Omega - TX12
| Manufacturer | Omega |
|---|---|
| Part Number | TX12 |
| Inner Code | 4984219 |
| Description | Intelligent Pt100 transmitter |
| Technical specification | input Sensor type: Pt100, 100 ohms at 0°C, 2 or 3-wire connection Sensor range: -200 to 850°C output Output type: 2-wire connection, 4-20 mA current loop General technical data Refresh interval: 500 ms Response time: 1 second Start time: 4 seconds (output current below 4 mA during start time) Warm-up time: 1 minute to full accuracy Power supply: 10 to 30 V DC ambient Ambient temperature range: -40 to 85°C Storage temperature: -50 to 90°C Ambient humidity range: 10 to 90% RH, non-condensing Mechanical characteristics Dimensions: 43 mm diameter; 21 mm height |
Please contact us to request a price quote for Omega - TX12, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
