Olaer (Parker) - EBV 475-10/90-P25C-H200
| Manufacturer | Olaer (Parker) |
|---|---|
| Part Number | EBV 475-10/90-P25C-H200 |
| Inner Code | 4960188 |
| Description | Bladder accumulator |
| Technical specification | Acc. Drawing 01-MB04021-3 Volume gas V0 473 l Design pressure 10 barg Design temperature -20 .. +100 °C Max. allowable working temp. -20 .. +100 °C Pre-charging without, must be filled to 3.7 barg by the end-customer before commissioning Material carbon steel Bladder material NBR25 Surface treatment ISO 12944 C3-H, RAL 6001 Process connection 6" ANSI 150 lbs Drain / Vent G ½" Con. gas-filling valve 5/8"-18 UNF and minimess Execution With mounting brackets Lifting lugs Approval CE, PED 2014/68/EU Non-destructive testing acc. to Code PMI No Nozzle loads No Wind loads No Seismic loads No Customer specifications No |
Please contact us to request a price quote for Olaer (Parker) - EBV 475-10/90-P25C-H200, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
