Obl - XLB25.50MMA40M3652
| Manufacturer | Obl |
|---|---|
| Part Number | XLB25.50MMA40M3652 |
| Inner Code | 4494482 |
| Description | Hydraulic diaphragm dosing pump |
| Custom Code | 8413 1900 |
| Technical specification | ATEX with double diaphragms, double valves Ex-protected electric drive max. flow rate: 105 liters/hour max. outlet pressure: 12 bar Internal safety valve (factory setting to): 15 bar Piston stroke: 15.25 mm Materiale: Dosing head: AISI 316L stainless steel Valve seats: AISI 316L stainless steel Valve balls: stainless steel AISI 316L Valve guides: stainless steel AISI 316L Valve seals: Vitob (FKM) Double valve body: AISI 316L stainless steel Double membranes: PTFE (1 x hydraulic side, 1 x medium side) Fluid inlet/outlet: 1/2" DN15, PN40 flanges Internal pressure relief valve in the hydraulic circuit, valve for replenishment in oil circuit, vent valve, Manual stroke adjustment from 0 - 100% (quantity setting) via micrometer screw EX - motor 4 pole, TEFC, 3 phases, 0.37 kW, 230/400 volts 50 Hz, IP55 XLB25.50MMA40M3652 ATEX II 2G Eexd (A) IIB T4 Pump is certified to API675 |
Please contact us to request a price quote for Obl - XLB25.50MMA40M3652, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
